12V DC Electric Solenoid Valve Water Air N/O 1/4\" Brass Body Normally Open Type with 2W025-08-K Wire Lead OEM Customizable

SPECIFICATIONS

Body Material: Brass

Color: Black & Silver

Port Size: 1/4''

Seal Material: NBR or FKM

Standard or Nonstandard: Standard

Supply Voltage: 12~240V AC/DC

Voltage: Dc 24V,AC 110 V,Dc 12V,AC 220 V,AC 240V

application: General

brand name: EPSolid

customized support: OEM

media: Base

model number: 2W025-08-K

place of origin: Zhejiang, China

port size: 1/8'' or 1/4''

power: Solenoid

structure: Control

temperature of media: Medium Temperature

warranty: 1 years

Product Description

Specification:
Model 2W025-08-NO
Voltage DC12V,DC24V,AC110V,AC220V
Operation Mode Normally Closed (valve opens when energized)
Valve Type Direct Acting, Wet Armature
Inlet/Outlet Ports G1/8'' or G1/4" Female (NPT Threads)
Max Pressure Rating Air/Water/Oil: 0-7Bar
Suitable Media Air, Water, Very Low Viscosity Fluids, Vacuum
Cv Value 0.4
Temperature -5-85'c degree
Valve Response Time Very Fast Acting
Duty Cycle Continuous (can be left powered without overheating)
Materials Valve Body BRASS
Plunger Tip Nitrile Butadiene Rubber (NBR)
Mounting Position Coil up preferred



Description:
With solenoid operated for control appropriate flow and direction, provide great performance.
Sturdy body have a long lifespan, perfect for electrically driven pneumatic power control.
